TP-Link TL-SF1005D 5-Port Unmanaged 10/100M Desktop SwitchSupports IEEE 802.3x flow control for Full Duplex mode and backpressure for half-duplex mode Supports MAC address auto-learning and auto-aging Standards and Protocols: IEEE802.3, 802.3u, 802.3x, CSMA/CD, TCP/IP Ports: 5x 10/100Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) Basic Function: Wire-speed Performance MAC Address Auto-Learningand Auto-aging IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode Backbound Bandwidth: 1Gbps MAC Address Table: 1kForwarding Rate: 10BASE-T: 14880pps/port 100BASE-TX: 148800pps/port 100Base-Tx: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100?? STP (maximum 100m) LED Indicator: Power, Link/Act (1, 2, 3, 4, 5) Safety & Emission: FCC, CE Power: External Power Adapter Transmission Method: Store-and-Forward Network Media: 10Base-T: UTP category3, 4, 5 cable (maximum 100m) EIA/TIA-568 100? STP(maximum 100m)
ETHERNET SPLITTER - Connectivity to your router or modem for additional wired connections (laptop, gaming console, printer, etc)
5 Port FAST ETHERNET - 5 10/100 Mbps auto-negotiation RJ45 ports greatly expand network capacity
COST EFFECTIVE - Fanless Quiet Design, Desktop design. Operating Temperature: 0?~40? (32?~104?)
RELIABLE - IEEE 802.3x flow control provides reliable data transfer
UP to 68% Power Saving - Automatically adjusts power consumption according to the link status and cable length
AUTO-NEGOTIATION - Supports Auto-MDI/MDIX, eliminating the need for crossover cables
Unlimited 24/7 technical support for FREE
The Power LED is not lit : The Power LED should be lit when the power system is working normally. If the Power LED is not lit, please check as follows: Make sure the power cord is connected to the switch with power source properly. Make sure the voltage of the power supply meets the requirements of the input voltage of the switch. Make sure the power source is ON. The Link/Act LED is not lit when a device is connected to the corresponding port. It is recommended that you check the following items: Make sure that the cable connectors are firmly plugged into the switch and the device. Make sure the connected device is turned on and working well. The cable must be less than 100 meters long (328 feet).
